descriptive | Parameter description | note |
Maximum cargo size mm | L420*W650*H400 | adaptable |
Minimum cargo size mm | L100*W100*H5 |
|
Maximum cargo weight kg | 5kg |
|
Minimum cargo weight kg | 0.05kg |
|
running speed | 1.2-1.6m/s |
|
Maximum Sorting Efficiency | 10,000 pieces/hour (based on minimum shipment) | Conventional efficiency 8000 |
Trolley pitch mm | 500mm |
|
trolley belt | Black PVC, low friction, small wrap-around corners |
|
Trolley running power | 48V servo electric roller | forward and backward |
Power per trolley KW | 0.4KW |
|
Main travel power | Permanent magnet synchronous linear motors |
|
Linear motor power KW | 3.5-5.5KW (according to the load, speed power change) |
|
Rated power of the whole machine KW | Trolley power + linear motor power |
|
operating noise | Half the rated power (needs to be adjusted for the number of grids) |
|
Sorting correctness | 70 dB or less | One meter from equipment |
Trolley pitch mm | 99.999% |
|
Fuselage Material | Aluminum alloy + sheet metal cladding |
|
Gusset Style | Slip Chute, Powerless Roller, Foley Wheel |
|
Trolley power supply method | Slip wire (standard) |
|
Trolley communication method | Distributed Leakage Cable Wireless Communications |
|
